PRODUCT SPECIFICATIONS
Compatible profile - Panelco (European) Solarspan (Australia)
Rib height (mm) - 43
Cutting capacity – Galvanized steel (mm) - Up to 1
Cutting capacity – Pre-painted steel (mm) - Up to 1
Notch width (mm) - 66 at base – 25 at top
Notch height (mm) - 43
Operation type - Manual lever
Cutting tolerance (mm) - +/- 0.5
Available to cut hips- No
Blades - High-strength hardened steel
-Replaceable - Yes
-Sharpenable - Yes
-Interchangeable - No
Dimensions (L × W × H) (mm) - 560x130x150
Net weight (kg) - 6
Product Code - PFN-61
RECCOMMENDED ANGLE OF FOLD FOR FLASHING/TRIM - 50° (on a sheetmetal folder) with a 43mm turndown
